MOD. Infrabator

Technical Features
  • Compact outer casing powder painted
  • Stainless Steel Chamber, without welding and with 100% rounded corners
  • Perfect insulation enviro-friendly, CFC-free
  • Warm wall heating: tacful and uniform
  • Door with automatic heating system
  • Inner tempered glass door easy to clean
  • Silicone gaskets
  • Removable shelving system, no tools
  • N04 flat shelves
  • Easy to check control compartment
  • DIGITAL microprocessor system
  • Alarm and autodiagnostic
  • Calibrable according to Int. Standards
  • PID control with autotune function
  • Double Displays: actual and set temp.
  • PT100 probe
  • Temperature range from +5C above ambient to +60C
  • Accuracy 0.1C - Uniformity 0.5C
  • Double DISPLAYS: actual and set CO2%
  • INFRARED system
  • CO2 range from 0 to 20%
  • Accuracy 1% at 5% CO2
  • Tube for control
  • Removable umidity pan easy to clean
  • Umidity 90% at 37C
  • PID DIGITAL Microprocessor UR%
  • Power supply 220 V 50 Hz
  • CE Approval

OPTIONAL AUTOMATIC DECONTAMINATION SYSTEM

CODE Int. Dim.
(wxdxh) mm
Ext. Dim.
(wxdxh) mm
Volume Power Weight
GINFRAB030 340x300x306 450x450x600 31 lt. 200 W 45 Kg.
GINFRAB060 308x400x510 420x550x805 61 lt. 400 W 60 Kg.
GINFRAB144 500x480x600 610x630x895 144 lt. 200 W 80 Kg.
